Ultra-high molecular weight polyethylene (UHMWPE) outrigger pads are a high-performance material widely used in the support legs of heavy machinery and equipment such as cranes, pump trucks, and lift trucks. This material is known for its excellent physical and chemical properties, including high wear resistance, high impact resistance, good corrosion resistance, and dimensional stability.
For large-sized UHMWPE outrigger pads, they are usually customized according to the specific needs of the equipment.
Small pump truck: The outrigger pad size is usually 400mm×400mm or 500mm×500mm, and the thickness is between 25mm and 30mm. Outrigger pads have good applicability and can meet the support needs of most small pump trucks.
Medium pump truck: The outrigger pad size may be 500mm×500mm, 600mm×600mm, and the thickness is between 50mm and 60mm. Pads of this size can provide better load-bearing capacity and stability, and are suitable for medium-sized pump trucks.
Large pump truck: The outrigger pad size may reach 800mm×800mm or larger, and the thickness may exceed 60mm, or even reach more than 100mm. Pads of this size can withstand greater weight and pressure, ensuring the safety and stability of large pump trucks.
These large-size pads are particularly suitable for large pump trucks or other engineering machinery that needs to carry heavier loads. They can provide more stable support and reduce machine tilting or instability caused by uneven or weak ground, thereby improving the safety of operation.
During the manufacturing process, UHMWPE outrigger pads need to undergo strict process control to ensure that they have sufficient strength and toughness to withstand extreme working conditions. In addition, since UHMWPE has a low coefficient of friction, it can also reduce wear when in contact with the ground and is easy to move.
If you need a specific size of UHMWPE outrigger pad, it is recommended to contact a professional manufacturer or supplier directly, who can customize the production according to your specific requirements.
